AirTAK C-UAS

$4,000.00
sold out

To purchase AirTAK C-UAS, please contact info@snstac.com

AirTAK C-UAS is a portable stand-alone FAA Remote ID receiver & TAK gateway. When deployed, AirTAK C-UAS displays UAS traffic within supported TAK Applications like ATAK, WinTAK & iTAK.

AirTAK C-UAS can be transported & installed by an individual or team, and remotely managed over cellular or other backhaul (IP Mesh, Satellite).

Use for airspace deconfliction, drone first responder DFR, airspace security & situational awareness.

  • Range: Up to 2 Miles.

  • Supported Applications: ATAK, iTAK, WinTAK, TAKX, TAK Server.

  • Supported Drones: DJI Mavic 3, Mini 3, DroneTag, DroneBeacon, Parrot, Cube

  • Supported Waveforms: WiFi 4, 5, 6, Bluetooth 4, 5.2, BLE

  • Supported Protocols: Open Drone ID (“Remote ID”), Cursor on Target (COT), TAK Protocol - Version 0, TAK Protocol - Version 1, JSON

  • Frequency Range: 2.4 GHz 5.8 GHz

  • IP Rating: Up to IP67

  • Dimensions: 11.9” x 8.5” x 4.8”

  • Operating Temperature: -40°C to 85°C

  • Power: 5.2 VDC at 3 Amps, Wh TK

  • Requires No Internet.

  • Plug & Play WiFi network connects directly to your TAK EUD.

  • Low EMS: Can be hard-wired to EUD.

  • Compatible with PAR Sit(x).
